Home   /   Products   /   Metal Wire System   /   PVC Coated Wire
Metal Wire System
< >

PVC Coated Wire

Material:Low carbon steel wire
Feature:Good insulating properties
Application:Construction building wire,handicrafts


Plastic coated iron wire in short is PVC wire, the product is made of high quality galvanized wire as raw materials, through the deep processing of the plastic and galvanized iron wire firmly together, has anti-aging, corrosion resistance, anti cracking characteristics such as life is several times the cold and hot galvanized iron wire.

PVC coated iron wire property: PVC wire offers excellent corrosion resistance and anti-aging property and longer service life compared with common galvanized iron wire.

PVC Coated Wire is manufactured with quality iron wire with plastic covering or plastic coating.

Material: Low carbon steel wire, Q195,SAE1008 (galvanized steel wire or annealed wire)

Inner Wire Guage: BWG4 ~ BWG25

Inner Wire Diameter: 6mm ~ 0.5mm

Tensile Strength: 300~500 N/mm2

Feature: Our PVC wire with good resilient, fire retardant and possesses good insulating properties,the color are green, grey,black,red or yellow. Other colors also available on request.

Package:
1.Bind with wire
2.plastic film inside and hessian cloth /woven bag outside
3.Carton
4.Other packing according customer`s requirement.

Weight of coil: 0.1-1000kg/coil, can be make as customers’requirement.

Application: PVC wire widely used in construction building wire,handicrafts, making wire mesh, Marine cable, product packaging, agriculture, animal husbandry and other fields.

PVC Coated Wire Specification:
Core Wire Diameter Outer Diameter
1.0mm -3.5mm
BWG.11-20
SWG. 11-20
1.4mm -4.0mm
BWG. 8-17
SWG. 8-17
P.V.C. Coating Thickness : 0.4mm -0.6mm
