| Material: | Stainless steel wire |
| Feature: | Corrosion resistance, Anti-acid and alkali |
| Application: | Liquid filter and other medium separation |
Material: stainless steel wire 304, 304L, 316, 316L, 310, 314, 410, 430.
Weaving type: plain weave, twill weave, dutch twill.
Wire diameter: 0.022mm - 3.5mm.
Features:
Anti-acid and alkali.
Direct filtration,simple process.
Good permeability.
Good regeneration performance.
High precision filter rating
Easy to install.
Has long work time.
High strength
Anti-high temperature.
Application:
In acid, alkali environment conditions sieving and filtering.
Petroleum industry as mud mesh.
Chemical fiber industry as screen mesh.
Plating industry as acid cleaning mesh.
In mining industry, chemical industry, food, medicine, etc
Mainly used for gas , liquid filter and other medium separation
| Mesh Count | Wire Dia. (Inch) | Width of Opening (Inch) | Open Area (%) | Opening (Micron) |
| 5 x 5 | .0410 | .1590 | 63.2 | 4046 |
| 10 x 10 | .0250 | .0750 | 56.3 | 1908 |
| 12 x 12 | .0200 | .0630 | 57.2 | 1603 |
| 14 x 14 | .0200 | .0510 | 51.0 | 1298 |
| 16 x 16 | .0180 | .0445 | 50.7 | 1132 |
| 18 x 18 | .0170 | .0386 | 48.3 | 982 |
| 20 x 20 | .0200 | .0300 | 36.0 | 763 |
| 30 x 30 | .0120 | .0213 | 40.8 | 542 |
| 30 x 30 | .0095 | .0238 | 51.0 | 606 |
| 40 x 40 | .0100 | .0150 | 36.0 | 382 |
| 50 x 50 | .0055 | .0145 | 52.6 | 369 |
| 60 x 60 | .0060 | .0107 | 41.2 | 272 |
| 60 x 60 | .0045 | .0122 | 53.3 | 310 |
| 80 x 80 | .0055 | .0070 | 31.4 | 178 |
| 100 x 100 | .0045 | .0055 | 30.3 | 140 |
| 100 x 100 | .0040 | .0060 | 36.0 | 153 |
| 120 x 120 | .0026 | .0058 | 47.3 | 148 |
| 150 x 150 | .0026 | .0041 | 37.4 | 104 |
| 165 x 165 | .0019 | .0042 | 47.1 | 107 |
| 180 x 180 | .0023 | .0033 | 34.7 | 84 |
| 200 x 200 | .0019 | .0030 | 60.6 | 77 |
| 230 x 230 | .0014 | .0029 | 46.0 | 74 |
| 250 x 250 | .0016 | .0024 | 36.0 | 61 |
| 270 x 270 | .0016 | .0021 | 32.2 | 53 |
| 300 x 300 | .0012 | .0018 | 29.7 | 46 |
| 325 x 325 | .0014 | .0017 | 30.0 | 43 |
| 400 x 400 | .0011 | .0014 | 31.4 | 36 |
| 500 x 500 | .0010 | .0010 | 25.0 | 25 |
